KV Rating: 150 KV

Turns: 9.5

Weight: 58g

Dimensions (D x L): 28.8 x 28.9 mm

Slots & Poles: 12N14P

Internal Resistance (Ri): 90.8 mΩ

No Load Current @10V (Io): 0.7 A

Number of LiPo Cells: 2–3S

Max. Efficiency Current: 14 A

Max. Burst Current (15S): 23 A

Max. Power (15S): 276 W

Max. Torque: 0.23 N·m

Shaft Diameter: 3.175 mm

Mounting Hole Pitch: 16/16

Input Connectors: GC3.5

Recommended ESC: XC-12-LITE or XC1218BA

Recommended Propellers:

• 2S: 11x7E, 12×6E

• 3S: 9×6E, 10×5E

Application Class: 400 size 400–800g sport airplanes
