ZTW LCD program card G2
Electronic Speed Controller Parts Item Code: ZTW-1400011
$62.20
Out of stock
ZTW Multifunctional LCD Program Box G2 for Beatles / Shark / Mantis / Mantis Slim G2 Series ESC Lipo Battery Voltmeter Servo Tester
The ZTW Beatles G2 Programming Box allows you to quickly and easily adjust the settings of your ZTW Beatles G2 - Mantis G2 - Skyhawk - Shark G2 - Seal G2 - Dolphin controllers.
Important: This device cannot work with old ZTW ESCs without G2 marking.Follow the simple instructions and you'll be programming your controllers in seconds.
Features- Working as an individual device to set the parameters for the ESC
- Working as a LiPo battery voltmeter to measure the voltage of the whole battery pack and each cell
- For the ZTW ESC with data returning feature, Possibility to display real-time data including voltage, current, input throttle, output throttle, RPM, battery power, MOS temperature and motor temperature
- For the ZTW ESC with data logging feature, the Possibility to read the data including maximum RPM, minimum voltage, maximum current, external temperature and maximum temperature
- PWM throttle signal detection
- ESC/Servo tester
- the LCD program box can be upgraded by the mobile App via the ZTW Bluetooth module
- Input Power Source: DC 5.0V～12.6V
- Weight: 40g
- Dimensions: 84mm x 49mm x 11.5mm
- ZTW Beatles G2 programming box
- Manual in English
